Single-stage vacuum pump
| Model | SN115 | SN125 | SN135 | SN145 | SN160 | SN180 | SN1100 | |
| Flow Rate | 50HZ | 1.5cfm | 2.5cfm | 3.5cfm | 4.5cfm | 6cfm | 8cfm | 10cfm |
| 42 L/min | 70 L/min | 100 L/min | 128 L/min | 170 L/min | 226 L/min | 283 L/min | ||
| 60HZ | 1.8cfm | 3cfm | 4cfm | 5cfm | 7cfm | 9cfm | 12cfm | |
| 50 L/min | 84 L/min | 114 L/min | 142 L/min | 198 L/min | 254 L/min | 340 L/min | ||
| Ultimate vacuum | 5 Pa | |||||||
| 150 microns | ||||||||
| Power | 1/4 HP | 1/4 HP | 1/3 HP | 1/3 HP | 1/2 HP | 3/4 HP | 1 HP | |
| Inlet port | 1/4' Flare | 1/4' Flare | 1/4' Flare | 1/4' Flare | 1/4' & 3/8' Flare | 1/4' & 3/8' Flare | 1/4' & 3/8' Flare | |
Two-stage vacuum pump
| Model | SN215 | SN225 | SN235 | SN245 | SN260 | SN280 | SN2100 | |
| Flow Rate | 50HZ | 1.5cfm | 2.5cfm | 3.5cfm | 4.5cfm | 6cfm | 8cfm | 10cfm |
| 42 L/min | 70 L/min | 100 L/min | 128 L/min | 170 L/min | 226 L/min | 283 L/min | ||
| 60HZ | 1.8cfm | 3cfm | 4cfm | 5cfm | 7cfm | 9cfm | 12cfm | |
| 50 L/min | 84 L/min | 114 L/min | 142 L/min | 198 L/min | 254 L/min | 340 L/min | ||
| Ultimate vacuum | 3× 10 -1Pa | |||||||
| 15 microns | ||||||||
| Power | 1/4 HP | 1/3 HP | 1/3 HP | 1/2 HP | 3/4 HP | 1 HP | 1 HP | |
| Inlet port | 1/4' Flare | 1/4' Flare | 1/4' Flare | 1/4' Flare | 1/4' & 3/8' Flare | 1/4' & 3/8' Flare | 1/4' & 3/8' Flare | |
