protection class: IP42/IP44
Insulation class: B
Environment Temp.:-40℃-+60℃
It used for refrigerators,freezers,food and beverage coolers,vending machines,
display cases and other fan duty applications.
| Model | Output (w) | Currrent @ Power Supply(A) | Speed (rpm) | Rotation | |
| Current when 220v/1p/50-60hz | Current when 115v/1p/50-61hz | ||||
| SN-UBM-2 | 2 | 0.14 | 0.28 | 1300/1550 | CW/CCW) |
| SN-UBM-4 | 4 | 0.16 | 0.32 | 1300/1550 | CW/CCW) |
| SN-UBM-5 | 5 | 0.18 | 0.36 | 1300/1550 | CW/CCW) |
| SN-UBM-6 | 6 | 0.2 | 0.43 | 1300/1550 | CW/CCW) |
| SN-UBM-9 | 9 | 0.32 | 0.64 | 1300/1550 | CW/CCW) |
| SN-UBM-14 | 14 | 0.21 | 0.48 | 1300/1550 | CW/CCW) |
| SN-UBM-16 | 16 | 0.48 | 0.92 | 1300/1550 | CW/CCW) |
| SN-UBM-25 | 25 | 0.6 | 1.1 | 1300/1550 | CW/CCW) |
| SN-UBM-35 | 35 | 0.76 | 1.5 | 1300/1550 | CW/CCW) |
| SN-UBM-50 | 50 | 1.2/1.0 | 2.2/2.0 | 1300/1550 | CW/CCW) |
