Minimum space requirement
Very compact design
High precision machining
To ensure the compressor come with the standard
CNC processing center
Concentricity due to specific processing technology
Energy efficient
High cooling capacity and minimum energy requirement:
Highly efficient working valves
Minimum clearance volume
Effiicient, large-volume motor
Reduced flow losses at low condensing temperatures
Steady operation
Quiet with low vibration
Optimized mass balance
Low discharge gas pulsations due to special cylinder head design
Excellent stability
Wear resistant drive gear
Surface hardened eccentric shaft and crankshaft
Low friction bearings and aluminium pistons
Hard chrome plated piston rings
Suction gas temperature 20℃,50Hz,without liquid subcooling.
Additional cooling or limited suction gas temperature.
Refrigerating Capacity R134a | |||||||||||||||||
Model | Condensing Temp ℃ | Refrigerating Capacity Qo(W) Power Consumption Pe(Kw) | |||||||||||||||
Evaporating Temperature(℃) | |||||||||||||||||
12.5 | 10 | 7.5 | 5 | 0 | -5 | -10 | -15 | -20 | -25 | -30 | -35 | -40 | -45 | -50 | |||
4YG-7.2 | 50 | Q | 18800 | 17100 | 15520 | 14050 | 9170 | 7230 | 5580 | 4190 | |||||||
P | 4.99 | 4.86 | 4.73 | 4.58 | 3.92 | 3.54 | 3.13 | 2.69 | |||||||||
60 | Q | 16160 | 14680 | 13310 | 12030 | 7770 | 6090 | 4650 | 3440 | ||||||||
P | 5.62 | 5.46 | 5.28 | 5.10 | 4.28 | 3.82 | 3.33 | 2.80 | |||||||||
70 | Q | 13580 | 12330 | 11170 | 10080 | 6460 | 5020 | 3800 | 2770 | ||||||||
P | 6.27 | 6.06 | 5.84 | 5.61 | 4.63 | 4.09 | 3.51 | 2.90 | |||||||||
4YD-6.2 | 30 | Q | 29550 | 26900 | 24450 | 22200 | 18170 | 14720 | 11770 | 9270 | 7170 | 5410 | 3950 | ||||
P | 4.35 | 4.28 | 4.20 | 4.10 | 3.89 | 3.64 | 3.35 | 3.04 | 2.70 | 2.33 | 1.95 | ||||||
40 | Q | 26000 | 23650 | 21500 | 19490 | 15910 | 12830 | 10210 | 7980 | 6100 | 4520 | 3210 | |||||
P | 5.25 | 5.13 | 5.00 | 4.85 | 4.54 | 4.18 | 3.80 | 3.38 | 2.94 | 2.48 | 2.00 | ||||||
50 | Q | 22550 | 20500 | 18630 | 16880 | 13740 | 11040 | 8730 | 6760 | 5100 | 3700 | 2540 | |||||
P | 6.08 | 5.90 | 5.72 | 5.53 | 5.11 | 4.66 | 4.17 | 3.66 | 3.13 | 2.57 | 1.99 | ||||||
4YG-9.2 | 50 | Q | 22550 | 20550 | 18640 | 16890 | 13750 | 11040 | 8730 | 6770 | 5100 | ||||||
P | 6.07 | 5.9 | 5.72 | 5.53 | 5.12 | 4.66 | 4.18 | 3.66 | 3.12 | ||||||||
60 | Q | 19250 | 17500 | 15870 | 14360 | 11650 | 9320 | 7320 | 5620 | 4180 | |||||||
P | 6.86 | 6.63 | 6.39 | 6.14 | 5.62 | 5.07 | 4.49 | 3.89 | 3.25 | ||||||||
70 | Q | 15970 | 14520 | 13160 | 11900 | 9620 | 7660 | 5980 | 4560 | 3350 | |||||||
P | 7.57 | 7.29 | 6.99 | 6.69 | 6.07 | 5.43 | 4.76 | 4.06 | 3.34 | ||||||||
4YD-8.2 | 30 | Q | 38400 | 35000 | 31800 | 28900 | 23600 | 19120 | 15280 | 12030 | 9280 | 6980 | 5080 | ||||
P | 5.05 | 5.12 | 5.16 | 5.16 | 5.05 | 4.83 | 4.53 | 4.15 | 3.73 | 3.28 | 2.84 | ||||||
40 | Q | 33950 | 30900 | 28050 | 25400 | 20700 | 16670 | 13220 | 10290 | 7810 | 5730 | 3990 | |||||
P | 6.63 | 6.52 | 6.39 | 6.24 | 5.87 | 5.43 | 4.93 | 4.40 | 3.83 | 3.26 | 2.69 | ||||||
50 | Q | 29350 | 26700 | 24200 | 21900 | 17730 | 14170 | 11110 | 8520 | 6320 | 4470 | 2930 | |||||
P | 7.88 | 7.64 | 7.38 | 7.10 | 6.52 | 5.89 | 5.23 | 4.54 | 3.84 | 3.14 | 2.44 | ||||||
4YG-12.2 | 50 | Q | 29100 | 26400 | 23900 | 21550 | 17390 | 13810 | 10750 | 8140 | 5940 | ||||||
P | 7.51 | 7.33 | 7.12 | 6.88 | 6.34 | 5.73 | 5.06 | 4.37 | 3.66 | ||||||||
60 | Q | 24450 | 22150 | 19990 | 18000 | 14420 | 11340 | 8710 | 6460 | 4560 | |||||||
P | 8.49 | 8.18 | 7.86 | 7.51 | 6.79 | 6.02 | 5.21 | 4.40 | 3.58 | ||||||||
70 | Q | 19850 | 17950 | 16170 | 14520 | 11540 | 8970 | 6760 | 4880 | 3290 | |||||||
P | 9.15 | 8.75 | 8.33 | 7.91 | 7.04 | 6.14 | 5.24 | 4.33 | 3.43 | ||||||||
4YD-10.2 | 30 | Q | 44850 | 40850 | 37150 | 33700 | 27550 | 22300 | 17790 | 13960 | 10730 | 8020 | 5760 | ||||
P | 5.88 | 6.01 | 6.08 | 6.10 | 5.99 | 5.73 | 5.33 | 4.84 | 4.30 | 3.73 | 3.17 | ||||||
40 | Q | 39600 | 36000 | 32700 | 29650 | 24150 | 19410 | 15360 | 11920 | 9000 | 6540 | 4480 | |||||
P | 7.63 | 7.56 | 7.45 | 7.29 | 6.89 | 6.38 | 5.77 | 5.11 | 4.41 | 3.70 | 3.01 | ||||||
50 | Q | 34200 | 31100 | 28200 | 25450 | 20600 | 16450 | 12870 | 9820 | 7230 | 5050 | 3220 | |||||
P | 9.11 | 8.85 | 8.56 | 8.26 | 7.58 | 6.84 | 6.05 | 5.24 | 4.40 | 3.58 | 2.77 | ||||||
4YG-15.2 | 50 | Q | 34700 | 31450 | 28450 | 25650 | 20650 | 16350 | 12680 | 9560 | 6930 | ||||||
P | 8.78 | 8.54 | 8.28 | 8.00 | 7.36 | 6.65 | 5.88 | 5.07 | 4.24 | ||||||||
60 | Q | 29250 | 26500 | 23900 | 21500 | 17170 | 13450 | 10270 | 7550 | 5260 | |||||||
P | 9.80 | 9.44 | 9.06 | 8.67 | 7.83 | 6.94 | 6.01 | 5.05 | 4.07 | ||||||||
70 | Q | 23850 | 21550 | 19380 | 17380 | 13770 | 10650 | 7960 | 5670 | 3720 | |||||||
P | 10.58 | 10.12 | 9.64 | 9.15 | 8.14 | 7.09 | 6.00 | 4.89 | 3.76 | ||||||||
4YD-12.2 | 30 | Q | 50900 | 46300 | 42100 | 38250 | 31300 | 25350 | 20250 | 15930 | 12290 | 9240 | 6700 | ||||
P | 7.45 | 7.40 | 7.33 | 7.22 | 6.93 | 6.55 | 6.10 | 5.58 | 5.01 | 4.41 | 3.79 | ||||||
40 | Q | 45300 | 41200 | 37450 | 33950 | 27700 | 22300 | 17680 | 13760 | 10440 | 7650 | 5320 | |||||
P | 9.16 | 8.97 | 8.75 | 8.50 | 7.95 | 7.33 | 6.65 | 5.92 | 5.17 | 4.39 | 3.61 | ||||||
50 | Q | 39550 | 35950 | 32600 | 29500 | 23900 | 19090 | 14980 | 11480 | 8510 | 6020 | 3930 | |||||
P | 10.79 | 10.45 | 10.09 | 9.71 | 8.88 | 7.99 | 7.05 | 6.10 | 5.15 | 4.22 | 3.34 | ||||||
4YG-20.2 | 50 | Q | 40250 | 36500 | 33000 | 29800 | 23950 | 18970 | 14690 | 11040 | 7940 | ||||||
P | 10.42 | 10.11 | 9.77 | 9.41 | 8.63 | 7.77 | 6.85 | 5.88 | 4.89 | ||||||||
60 | Q | 33900 | 30650 | 27650 | 24850 | 19850 | 15530 | 11830 | 8690 | 6020 | |||||||
P | 11.65 | 11.20 | 10.72 | 10.22 | 9.18 | 8.10 | 6.98 | 5.84 | 4.70 | ||||||||
70 | Q | 27500 | 24850 | 22350 | 20000 | 15840 | 12240 | 9150 | 6520 | 4300 | |||||||
P | 12.59 | 12.01 | 11.42 | 10.82 | 9.57 | 8.30 | 7.02 | 5.75 | 4.52 | ||||||||
4VD-15.2 | 30 | Q | 69100 | 62800 | 57000 | 51600 | 49150 | 33700 | 26700 | 20850 | 15920 | 11840 | 8500 | ||||
P | 10.40 | 10.07 | 9.74 | 9.41 | 8.74 | 8.07 | 7.38 | 6.67 | 5.95 | 5.20 | 4.42 | ||||||
40 | Q | 61300 | 55700 | 50400 | 45600 | 37000 | 29600 | 23350 | 18100 | 13700 | 10060 | 7080 | |||||
P | 12.46 | 11.93 | 11.43 | 10.93 | 9.97 | 9.04 | 8.13 | 7.23 | 6.32 | 5.39 | 4.44 | ||||||
50 | Q | 54100 | 49050 | 44400 | 40100 | 32400 | 25800 | 20250 | 15570 | 11660 | 8430 | 5800 | |||||
P | 14.24 | 13.54 | 12.87 | 12.22 | 10.99 | 9.81 | 8.69 | 7.59 | 6.51 | 5.43 | 4.34 |
