◆Oil separators should be installed vertically on the discharge line,as close as possible to the compressor

◆Connection diameter of the oil separators should be higher than or equal to the diameter of discharge line

◆In the case of a multi-compressor installation mounted in parallel,it is recommended to use one oil separator by compressor,in order to keep an optimal efficiency at all operating rates,otherwise,the separator should be selected based on the sum of each compressor's maximum capacity.

◆The oil separation performances will depend directly on the flow rate of the oil/refrigerant mixture at the inlet of the separators.

◆In order to prevent all risks of refrigerant condensation,it is recommended to not install the oil separators in the air flow produced by the fans,In a cold environment,it may be necessary to provide for the installation of an heat insulation or a heating element around the separators.

◆The efficiency of the oil separation is never 100%,especially with variable operating
